Axle Repair: Signs Of Failure And How To Fix Them

You turn the steering wheel and hear a clicking sound. It gets more prominent with each turn. At first, it’s somewhat frustrating but with more time, you start worrying about what’s up with your car. We have bad news. The reason behind this problem is quite serious, as you may have to consider doing an axle repair.

A car’s CV axles are an integral part of the acceleration and driving process, so when you ignore a potential problem, you are jeopardizing the lives of many, including yourself.

When you bring your car to the mechanics for this problem, they are likely to conduct a thorough inspection of the axles. Most of the time, this is where the issue is rooted. While it’s good to leave axle repairs at the hands of professionals who will do the best (and not ruin your car), you can also do it by yourself.

Don’t worry; it’s not as complicated as it looks. We’re here to guide you on the right path! But before all that, let’s talk in-depth about the signs that tell you your car’s axle needs to be fixed or replaced. In this article, we will cover:

• What Are Axles On A Car?
• Types Of Axles
• Signs Of A Bad Axle
• Durability Of Axles
• Repair/Replacement Costs
• DIY Repairs At Home
• Replace Your CV Axle
• Pro Tips And Tricks
• Axle Safety
• Insurance Coverage
• Driving With A Bent Axle
• Final Conclusion
• Frequently Asked Questions (FAQs)

Car Axle

On your vehicle, an axle is a shaft or rod that turns the wheels and supports the weight of the entire vehicle. They are essential elements of all vehicles. As axles regulate the power that rotates the wheels, they are a necessity for vehicles for proper operation.

For the majority of us, the word “axles” brings up the image of a bar amidst two wheels. Alternatively, it’s a straight axle similar to what you would find on a train car. In reality, most axles are much more complex than that.

Most axles in modern-day are split axles, meaning the wheel on both sides is linked to an individual shaft. This makes a smoother ride through independent suspension of the right and left wheels. It also lets the two wheels turn at varying speeds when the vehicle turns, boosting traction and increasing tire life. That’s what professionals call “differential”.

Types Of Axles

There are three types of axles in a car.

1. Rear Axle

The rear axle can be found between the driving wheels and the differential and it delivers power between the two. The differential connects two halves of the rear axle and each half is termed half shaft. In the majority of automobiles, the vehicle’s wheels and rear axles rotate together.

2. Front Axle

The front axle-regulated steering bears the load of the front part of the car and absorbs shocks when it is driven on uneven terrain.

3. Stub Axle

Stub axles carry the car’s front wheels.

The rear and front axles are responsible for turning the wheels. Generally, cars just have front and rear axles, but bigger vehicles could have more.

Bad Axle Symptoms

Your car’s axles should ideally be smooth and quiet. A number of things could damage the axles in your vehicle. The most common reason would be some kind of damage due to impact or an accident. Either you ran into something or hit another car, or maybe you ran roughly over a series of potholes or speed bumps.

Or, it could even be due to some junk on the road. Since the axle is right over the ground, uneven surfaces of any kind could potentially damage or bend it.

Though rare, a manufacturing error could be behind the bent axle too. When the axle is made, the metal has to be heat treated properly or it will develop weak spots. Thanks to this, the axle is vulnerable to normal wear and tear that it would have to endure at some point, causing it to break.

For example, industry legend Ford had to recall more than 30,000 F-250 and F-350 trucks in 2012 due to a defect found in the rear axle shaft. In another incident, GM recalled over 250,000 Pontiac, Saturn, and Cadillac models in need of rear axle repair where the seal on them was leaking. Owing to that, the cars would lose control and crash.

So, outside damages paired with possible manufacturing errors risk the axle’s integrity. Whatever the case, check if you ever have these symptoms. If yes, it’s time for a prompt repair:

Axle Repair, Symptoms #1: Bad Vibrations

A car with a bent axle doesn’t react well to collisions. After the automobile goes over an unexpected curb, a bad pothole, or any big objects, may indicate damage. In addition, vibrations may come with an unnatural rumbling noise beneath the vehicle, sluggish steering or driving, or weird tire wobbling. Vibrations might be slightly stronger during turns, accelerations, and decelerations.

If the condition persists during driving at slow speeds, know that there is certainly an issue with the axle. Unusual or excessive vibrations can deal damage the whole vehicle’s experience including handling, safety, and comfort.

Axle Repair, Symptoms #2: A Loud Sound

If there is a weirdly loud clanking, clunking, or clicking once you shift your car into gear, or if a vehicle is simply struggling to ever turn on, there could be axle-joint decay. This sort of noise usually means that the transmission is failing to transfer enough power to the wheels giving slack in the joints.

Moreover, a loud clunking noise may also indicate a transmission failure. This is where a professional assessment is mandatory.

Axle Repair, Symptoms #3: Leaking Grease

The rubber cover over the CV or axle joint is known as a CV boot or leaking axle boot. It can initiate the leaking of grease on the edges of the tire or under the car. Though a leaky axle boot does not always indicate that the axle has been damaged, insufficient oil caused by the leak can lead to future issues.

A joint cover that’s broken may also let dirt enter which might cause the failure of axle joints. You should carefully inspect boot clamps and axle boots on a regular basis to make sure there are no leaks or splits. They can be easily seen beneath a car.

To avoid a more serious breakdown of the axle system, you should repair a leaky axle boot as soon as possible.

Axle Repair, Symptoms #4: Going Too Slow

So, your car starts fine, shifts into gear, and even makes a normal engine sound ultimately disappointing you by not moving at all? This sounds like the case of a broken axle. In this case, after aggressive pressing of the accelerator pedal, the vehicle doesn’t move, and the engine solely revs. Until it’s repaired, the car will not move. Better get it fixed!

Axle Repair, Symptoms #5: Tire Movement

When your car is parked, try to move your tires back and forth. If the tires are moving too much, there is a high probability that there is something wrong with the axle. This unwanted movement in the tires may lead to the whole wheel coming off when driving, which is extremely dangerous. This is a clear indication that the axle needs to be inspected and repaired as soon as possible.

Axle Repair, Symptoms #6: Difficulty Steering

The axle is connected to the steering system of your vehicle. If there is a problem with your axle, it could lead to difficulties in steering. Your car might start pulling to one side, or you might feel a lot of resistance when trying to steer. This symptom can be especially noticeable when you are trying to make a turn. Don’t ignore this sign as it could lead to a dangerous situation on the road.

Axle Repair, Symptoms #7: Uneven Tire Wear

Axles help in the distribution of weight across your vehicle. If there is an issue with the axle, it could lead to uneven tire wear. This means that one side of your tire may be wearing out faster than the other. Regularly check your tires for uneven wear. If you notice any, it is important to get your vehicle inspected by a professional.

Axle Repair, Symptoms #8: Vehicle Shaking

Another common symptom of a damaged axle is when your vehicle starts to shake, especially at high speeds. This can be very alarming, especially if it happens on a busy road. This shaking might be accompanied by unusual noises from the undercarriage of the vehicle. Do not ignore this symptom as it could lead to a complete breakdown of your vehicle.

Axle Repair, Symptoms #9: Alignment Issues

Axles play a vital role in maintaining the alignment of your vehicle. If your vehicle starts drifting to one side while driving or if you notice that your steering wheel is off-center, there might be an issue with the axle. Getting a wheel alignment might fix the issue temporarily, but if the axle is damaged, the problem will keep recurring.

Axle Repair, Symptoms #10: Transmission Problems

The axle is connected to the transmission and helps in transferring power from the engine to the wheels.

If there is an issue with the axle, it could lead to transmission problems. You might experience issues like the vehicle not moving despite being in gear or the transmission slipping. This is a clear indication that there is an issue with the axle and it needs to be inspected immediately.

In conclusion, the axle is a crucial component of your vehicle and plays a vital role in its performance and safety. Regular inspection and maintenance of the axle are essential to ensure the smooth running of your vehicle.

If you notice any of the above-mentioned symptoms, it is important to get your vehicle inspected by a professional as soon as possible. Ignoring these signs could lead to a more serious problem and could be extremely dangerous.

How Long Do CV Axles Last

Axles are typically covered by the powertrain warranty provided by the manufacturer, which should have you covered for at least 4 – 5 years as well as 50,000 – 60,000 miles. Now arises the question of whether the axle lasts past the warranty period. A handful of factors can influence its lifespan.

Driving over rocky or dirt-filled terrains can definitely take a chunk off an axle’s lifespan as there are more chances of damaging the protective rubber boot. The same applies to driving in icy or snowy conditions, where sand and salt can negatively impact the rubber. The rubber can also dry out and crack in some cases, which has the same effect.

One interesting question that gets asked quite often is whether a damaged CV axle will wear out the transmission. An axle is directly connected to the transmission, so if it’s failing, it can surely damage it. If a damaged axle moves too much, it can wear the inner components much quicker than it normally would.

Car Axle Repair Cost

We mentioned the different kinds of axles before. Costs of axle repair differ from rear to front. The average cost of repairing a front axle is about $550. You have to pay a bit more for rear axles; the average is $800. Axle repair costs depend on the make, model, and type of vehicle.

1. Bent Or Broken Axle Repair Costs

For the most part, a bent or broken axle has to be replaced. These costs include the price of the parts and labor fees. However, there will be some additional taxes associated with the county or state you are residing in.

2. Front Axle Repair Costs

You have to pay between $500 to $600 for front axle repair costs before fees and taxes. Again, costs vary depending on the make, brand, vehicle, and model. Labor costs range between $50 to $140 based on how long it takes for the job to be done.

3. Rear Axle Repair Costs

In rear axle repair, the parts are rather expensive and make up the lion’s share of the total price. Expect to spend anywhere from $700 to $900. Labor charges are $50 to $70.

How Much To Fix Car Axle

Good news for DIY enthusiasts and savers! You can surely replace an axle at home but you have to be comfortable using a handful of power tools. Assuming you already have most of the required equipment set up at home, the axle repair cost comes down significantly. Most online outlets and part stores will sell you a brand-new axle for under $100.

Estimated time required: One to two hours, depending on your comfort and skill level

Skill level: Advanced beginner

Vehicle system: Suspension/drivetrain

Here’s a list of everything you will need for the job. An impact wrench isn’t compulsory but it will surely make the process a whole lot easier. Plus, it’s safer to have one on hand since you won’t have to stress about torquing the axle nut. An axle repair bearing guide could be helpful too.

List Of Tools

• Automotive toolset (screwdriver, pliers, sockets)
• Jack
• Jack stands
• Pry bar
• Braker cleaner
• Lubricant
• Mallet or hammer
• Impact wrench (optional)

List Of Parts

• Replacement cotter pins
• Replacement axle

We suggest you organize your gear and tools so everything can be accessed easily when needed. This will save you precious time. Every time you take a bolt of something out, make sure to label it.

You’ll also have to work on a flat surface, like a garage floor (fun fact, go check out our guide on the square footage for 2 car garage), street parking, or driveway (another fun fact, go check out our guide on how to clean oil off driveway).

Axle Replacement

The given process is a general guide to replacing an axle. Your automobile may be a little or drastically different because as stated multiple times before, changes exist between models and make. Refer to your owner’s manual to confirm you’re following the right steps.

At one point, you will see us recommending you use an impact wrench to take the axle nut out. Having said that, doing it by hand is better if the car is on the ground. In this case, step five has to be performed prior to jacking the car up. You can also check out this video for a brief introduction to axle replacement.

1. Removing The Axle Nut

1. Confirm the vehicle is in “Park” gear.
2. Raise the car and take out the wheel on the side(s) where the axle has to be replaced.
3. Find the axle nut. It’s in the exact center of either the wheel assembly or the hub where the wheel was removed.
4. There is a cotter pin in some vehicles to hold the axle nut. Use pliers to adjust the pin so you can pull it out. You can give it a spray of lubricant if it’s stuck or rusted.
5. Now you must unfasten the axle nut. Don’t get demotivated if this takes time to do because it happens with some car models. Under the circumstance that you’re totally unable to complete this, lower the car and do it before jacking up the car. This is where the impact wrench can show you a bit of its magic. It can help you remove the axle nut safely without taking a breaker bar to your car.

2. Removing The Brakes, Steering Knuckle, Struts, And Tie Rods

1. Now, remove the blots carefully, securing the brake caliper brackets in position. Don’t let the caliper dangle on the brake line. Instead, use any small hook or carabiner to secure the caliper. This also releases excess pressure off the line.
2. Unfasten the bolts keeping the steering knuckle and the outer tie rod together. Check if there are any extra pins there. If yes, use the pliers to straighten them out. The process won’t be that easy in some cases. Bring out the hammer or mallet and do a few light taps on it to loosen it up.
3. Hold the hub against the strut tower and take out the bolts. You must keep the nut from rotating while undoing the hub.

3. Removing And Replacing The Axle

1. Inspect the axle’s line to check where it connects to the transmission. Using a pry bar, pry the CV joint and axle. At this point, the axle should come off without fuss. You may notice some leak or transmission fluid while prying. This is totally normal, but we recommend you set up a tray or pan to catch the fluid.
2. Introduce the new axle into the joint (transmission-axle) where the old one was taken out. You can use a hammer or mallet wrapped in a towel to gently push the axle into place.
3. Connect the new axle with bolts to the hub. Follow this order: Strut tower/Hub, Steering knuckle/Tie rod, Caliper
4. Change the axle nut. An impact wrench will be your friend here as it can help you safely secure the nut. In case you don’t own one, tighten the nut to the best of your ability without pulling on it when it’s up on the stands.
5. Change the wheel. You’re almost done – lower the vehicle. And this is the time to fasten the axle nut if needed. You don’t have to worry about the vehicle falling so push on a bar or wrench to tighten the nut.

How To Replace A CV Axle

Check out some tips and tricks to do the best job at replacing the axle.

• If you don’t have a garage, do this on the flattest surface you can find. The car has to be safely raised on jack stands which isn’t possible if your work surface is inclined.
• Wear protective eye gear and gloves to protect yourself during these projects. There isn’t a dearth of opportunities to hurt yourself.
• Read the instructions multiple times before starting. Also carefully go through your owner’s manual in case there’s something that might influence the process. The pro to reading the process many times is not only are you acquainted with it now, but you can also detect if any part of it is making you uncomfortable. If it does, it’s best you let a professional get this done.

Starting and then deciding halfway that you don’t have the willpower to finish it is going to be harmful to your car.

• Inspect other parts when working on the axle. You can check for damages on the brakes and other suspension parts too. It’s only logical that you perform two fixes consecutively while the car is on stands and the wheels are off.

Safety Tips

Apart from the evident mess that you will be creating while working on your car, it’s also quite dangerous. Before anything, we need to make sure you don’t lose a finger, get maimed, or die (yes, unfortunately, that’s a possibility). Stay safe!

• A flat surface will be very great in keeping the mess to a limit.
• Don’t shake or yank the automobile when it’s on axle stands. If you truly must torque the axle nut down, lower the vehicle to the ground first so you can use the wrench without worry.
• Don’t miss out on any bolt or component when reassembling the vehicle. Failure to do so properly will result in dangers similar to a failing axle.

Will Insurance Cover Axle Repairs

Cared for correctly, many axles can serve the vehicle for a lifetime. Although insurance doesn’t include routine repairs (you can learn more in our guide on how to cancel Progressive insurance), it might cover axle repairs. But that can be the case if the axle is damaged by a covered item.

Policies with collision coverage could pay for the axle repair if an auto accident caused it to break. A few policies even provide coverage for harsh weather. Score a good deal on a policy – make sure it covers multiple conditions.

What Happens If Your Axle Breaks While Driving

Depending on the following, you can know whether it’s safe to drive with a bent axle.

Slightly Bent Axles

If the axle is bent only slightly, you can drive like that for a brief period. However, you will experience vibrations and rough turns during the ride. If left unattended too long, the bent axle will damage hubs, CV joints, and bearings. Post-accident, if you feel way too many vibrations, get the vehicle to a collision repair center.

Severely Bent Axles

Any axle bent over a quarter inch isn’t fit for driving. It will have to be towed to the mechanics and the axle must be replaced before anyone gets on it. Badly bent axles will be quick to damage CV joints as well as wheel hubs, bearings, and additional powertrain components.

Axle Repair Costs and Symptoms – Need-to-Know Facts

1. The average cost to repair a front axle is $550, while the average cost to repair a rear axle is $799, depending on the vehicle’s make and model.
2. In most cases, a bent axle cannot be repaired and must be replaced, which includes parts and labor costs but not taxes and fees.
3. The cost to repair a front axle ranges from $500 to $600, while the cost to repair a rear axle ranges from $430 to $480 for parts and $50 to $70 for labor.
4. Bent axle symptoms include instability, noise, leaks, and vibration in the vehicle and steering wheel.
5. A bent axle can ruin the alignment of a vehicle, causing it to pull to one side and wobble while driving.
6. Noises such as clunking or clicking while driving could be a sign of problems with the axles.
7. Grease leaks around the tires could indicate a failed CV joint, which is located near the wheels and can leak grease if cracked.
8. Vibration during driving, especially in the steering wheel, could indicate a bent axle, wheel, or misaligned alignment.
9. Severely bent axles cannot be driven on, while slightly bent axles can be driven on for a short time but may cause damage to other components if left too long.
10. The axles, along with the transmission, are essential to the proper functioning of a vehicle and the transfer of power from the engine to the wheels.

Axle Repair: In Conclusion…

With a damaged or broken axle, your car will only last a limited time before causing severe complications. It could malfunction a little or break down completely. You shouldn’t put off axle repairs as losing an axle during driving could put you through a violent accident, causing harm to yourself and others. At the first symptoms of a failing car axle, consider fixing it yourself or handing it over to a mechanic for fixes.

Axle Repair: Frequently Asked Questions (FAQs)

If you’re still curious to learn more about axle repair, our FAQs here might help…

How Many Axles Does A Car Have

Most vehicles in the world come with two axles – one for the front pair of wheels, and another for the rear pair of wheels. After all, an automotive ‘axle’ is defined as a cylindrical rod that connects two wheels across the length of a vehicle, from one side to the other (basically, left to right). In other words, the wheels are conjoined on a shared axis. However, not all cars pair two wheels to a single axle. Highly specialized and heavy-duty vehicles, such as big pickups or semi-trucks, may have four or even six wheels connected to a singular axle. This allows them to better distribute their weight throughout the vehicle. Plus, it aids in improving grip and traction on the road. Still, most passenger cars out there only have two axles.

What Is An Axle

In engineering terms, an axle is a central shaft that is used in the rotation of a wheel or gear. But in the car world, the axle is simply a cylindrical rod that connects two wheels across the length of a vehicle, from left to right. For example, there’s an axle that connects the front left and front right wheels together. In doing so, they’re now joined across the same axis. Besides that, the axle is mainly responsible for transferring torque and power from the transmission onto the wheels to get your car moving. Therefore, an axle is a crucial component for regulating power to your wheels. And, allowing them to spin and move your car around. The axles are also connected to your car’s differential, which allows the two wheels to rotate at varying speeds, thus making turning much easier.

What Is A CV Joint

If you’re driving a front-wheel drive vehicle, then your car most likely has a CV joint. Or, as it’s otherwise known, the Constant Velocity joints, which can be found on both ends of the driveshaft. The CV joints are then split into two – the inner CV joints, and the outer CV joints. The inner CV joints connect the transmission to the driveshaft. Meanwhile, the outer CV joints connect the wheels to the driveshaft. So, why does your car have a CV joint? Well, it’s required to ensure that your car’s transmission is able to transmit power effectively through the driveshaft and onto the wheels. While at the same time, needing to cope with the bumpy up-and-down motion of the suspension. For FWD cars, it also allows the transfer of torque to the front wheels while you’re turning.

What Is A CV Axle

Front-wheel drive cars are far more complex than they seem. Primarily, it’s the fact that the front wheels have to handle steering, power delivery, most of the suspension work, as well as much of the braking force, all at once! One of the key pieces of innovation that have made all this possible is CV axles. Or, as some might call them, the Constant Velocity axles. They’re also known as half-shafts, which connect the transmission, driveshaft, and wheels together. In short, it aids in delivering power from the engine to the driven wheels. But at the same time, the CV axles are designed to compensate for the constant movement of the front wheels – like suspension movements up and down or turning lock to lock – while they’re passing along torque and power to the wheels.

How To Tell If CV Axle Is Bad

Seeing how much strain and force your CV axle has to go through every single day, they’d wear out sooner or later. When they do, it’s usually fairly easy to tell. Among the most obvious symptoms of a worn-out CV axle are the odd sensations you get from the steering wheel. For example, you’re able to feel excess vibrations, and shakiness, in addition to clicking and knocking sounds while you’re turning. Beyond that, you could also try inspecting the CV axle’s rubber boots to see if there’s any damage there, as well. Any tears or visible wear should be addressed promptly. Moreover, you could also see if there’s any grease on the outside of those rubber boots. Without proper lubrication, your CV axles won’t be able to function as well as it’s supposed to.

How Much Is a CV Joint

The cost of a CV joint can vary widely based on the make and model of your vehicle, and whether you’re buying a single joint or a whole axle. Typically, a single CV joint can cost between $50 to $150. However, if you are buying a whole axle, which includes both inner and outer CV joints, it can cost anywhere from $150 to $400.

How Much Does It Cost to Replace a CV Joint

The cost to replace a CV joint will typically range from $300 to $1,000, including both parts and labor. Labor costs can vary from one location to another, and this is often the most significant factor in the overall cost of the replacement.

What Happens If Your CV Axle Breaks While Driving

If your CV axle breaks while driving, you will likely lose control of the vehicle. This is because the axle is what transfers the power from your engine to your wheels. A broken axle means no power to the wheels, which could result in a very dangerous situation.

How Much Is an Axle Replacement

The cost of an axle replacement can vary widely based on the make and model of your vehicle, and whether you are replacing a front or rear axle. Typically, it will cost between $200 to $1,000 for both parts and labor.

Can Broken Axle Damage Transmission

Yes, a broken axle can potentially cause damage to the transmission. The axle is connected to the transmission and if it breaks, it can cause excess strain on the transmission or cause it to become misaligned.

How Many Axles Does a SUV Have

Most SUVs have two axles, one at the front and one at the rear. However, some larger SUVs or those with all-wheel drive may have more.

What Does a Broken Axle Look Like

A broken axle may have visible signs of damage such as cracks, bends, or even a complete break in the shaft. Additionally, you may hear a loud clunking or banging noise when driving, or the vehicle may pull to one side.

How Much Does It Cost to Replace a Rear Differential

The cost to replace a rear differential can vary widely based on the make and model of your vehicle. Typically, it will cost between $1,000 to $3,000 for both parts and labor.

How Long Can You Drive With a Broken Axle

It is not safe to drive with a broken axle. A broken axle can cause loss of control of the vehicle and potentially lead to an accident. If you suspect that your axle is broken, it is best to have it repaired immediately.

Is a Slightly Bent Rim Dangerous

A slightly bent rim may not be immediately dangerous, but it can cause uneven tire wear, and vibrations while driving, and can potentially lead to a flat tire. It is best to have a bent rim repaired as soon as possible.

How Much Is a Front Axle Replacement

The cost of a front axle replacement can vary based on the make and model of your vehicle. Typically, it will cost between $200 to $1,000 for both parts and labor.

How Long Does It Take to Fix a Broken Axle

The time it takes to fix a broken axle can vary based on the extent of the damage and the make and model of your vehicle. Typically, it can take anywhere from 2 to 4 hours for a professional to replace an axle.

What Connects the Tire to the Car

The wheel hub assembly connects the tire to the car. The wheel hub assembly includes the wheel hub, bearings, and wheel studs, and connects to the axle or CV joint.

How Much Does It Cost to Replace a Drive Shaft

The cost to replace a drive shaft can vary based on the make and model of your vehicle. Typically, it will cost between $300 to $1,500 for both parts and labor.
