How Much Do Traffic Lights Weigh: Is The Average Weight Heavy?

As we commute daily, we see traffic lights, but their weight is not a priority to us. All we want is for them to go green so we can move. However, if you are curious and are asking how much do traffic lights weigh, then here is your answer.

A typical aluminum traffic signal weighs 37 lbs. The weight depends on the size of the traffic light and material. Traffic lights are made from aluminum or plastic. Older ones were made from cast iron, and their weights vary.

Traffic lights are a vital part of the transportation system. They help to coordinate and regulate traffic flow, as well as provide information about the status of the roadways. With that in mind, we decided to look into these pieces of infrastructure. This article has all the details about traffic light weights, sizes, and build.

Traffic Light Size

Traffic lights come in 8 to 12 inches lens sizes. They are standardized in size, color, and shape to make them easy to see. Traffic lights with 8-inch lenses are 30 inches tall, 9.5 inches wide, and 6 inches deep. The 12-inch traffic light lenses are 8 inches deep, 42 inches tall, and 13.5 inches wide.

An 8-inch signal is preferable in some locations, while a 12-inch light is more preferred in others. However, they are both popular in different parts of the world and aim at reducing accidents and keeping people safe in their respective areas of residence.

You can see the big traffic light lenses (like the 42-inch traffic light) in high-traffic areas, such as New York City. This is not to say that only large traffic lights are useful. Many states prefer eight-inch lenses over 12-inch lenses because they have more customizable features.

That explains why traffic signal lenses in the UK are just 8 inches in diameter. Manufacturers produce them with high visibility lenses, enabling motorists to see them at a distance. There are a few hybrid stoplights in Canada, although not as prevalent as stoplights with 8 and 12-inch lenses.

Traffic Light Dimensions

Traffic lights are made in many different dimensions. They can have three, four, or five different patterns of lenses. Three-lens traffic lights are available in two sizes. These designs come in either an 8-inch or 12-inch lens pattern.

Traffic lights are available in many sizes and shapes to accommodate different roadways and intersections. For example, smaller residential neighborhoods or back roads with little room for larger traffic lights use the mini traffic lights. The mini traffic lights are also good options for people who want to create their own signs.

Traffic Light Actual Size

Traffic light sizes vary, but the standard size is 8 inches diameter lens. The smaller size of these traffic lights makes them easier to see from cars and allows for more flexibility when placing them on a pole.

The traffic light pole is the vertical pole that supports the traffic light. Traffic light poles are 9 to 14 inches tall and about 18 inches above the ground.

Stop Lights

Stop lights are just another word for traffic lights. They’re termed robots in South Africa. Stop lights are signaling devices placed at road intersections, pedestrian crossings, and other locations to control traffic flows.

They typically consist of three signals communicating meaningful information to drivers and riders via colors and symbols such as arrows and bicycles. The standard traffic light colors are red, yellow, and green, in that order, arranged vertically or horizontally. Although this is internationally standardized, variations in traffic light sequences and laws exist nationally and locally.

Traffic Light Compared To Human

The 8-inch traffic light lens measures 9.5 inches broad and six inches deep, that’s about the size of a human’s head. The full traffic light measures up to four feet, taller than some people. This is for the lights and not the pole. Of course, those poles vary between 9 and 14 feet. They are taller than most humans.

What Effect Do Local Laws And Populations Have On Traffic Lights

In every state in the US, the government documents and implements the laws governing the size of traffic lights and their lenses. Traffic light laws also govern where and how high engineers can place a traffic light above the road. Increased confusion and accidents can occur if you install traffic lights on every street in the state.

Outside safety concerns, the manufacture and installation of traffic lights are way too expensive. As a result, some states consider budgetary constraints when making traffic light regulations. However, the department of transportation in your state is responsible for ensuring that contractors follow these regulations.

How Much Do Traffic Lights Weigh

Traffic Light Weight

Aluminum traffic lights weigh 37 pounds, but plastic (polypropylene) ones weigh less. Currently, manufacturers produce new traffic lights with aluminum or plastic. However, older ones were made of cast iron. The design of a traffic light will also affect its overall weight

Traffic Light Height

The traffic lights are about four feet tall on average. The lights inside are typically 12 inches in diameter, but roads with little traffic use 8-inch lights. Traffic lights must be visible so drivers can see and obey their signals. Traffic lights are typically 18 feet above the ground.

Height Requirement

According to the Manual on Uniform Traffic Control Devices for Streets and Highways, a stop sign must be at least 7 feet tall in urban areas and 5 feet tall in rural areas. The height of a stop sign has a standard to ensure that drivers can see it when approaching an intersection that requires them to stop.

Traffic Light Cost

Traffic signals are much more expensive than most people realize, even though they are an excellent public investment when justified. Depending on the intersection’s complexity, a modern signal can cost between $200,000 and $500,000 to install, including marking pavements, pedestrian access ramps, and utility adjustments.

Traffic Light Weight Sensors

Every traffic light signal has a sensor or timer to regulate traffic flow. Several vehicles cross road intersections daily, where timed traffic lights help to make this possible. Inconsistent traffic flows are efficiently curtailed on country roads with the aid of traffic signal sensors (detectors).

They detect when cars arrive at intersections, a lineup of vehicles at an intersection, and when cars enter turn lanes. Sensors in traffic control systems, at their most basic, detect the presence of vehicles at specific points. Sensors can count and monitor the number of vehicles passing through a particular point and the speed at which the cars travel.

You can use sensors in many traffic control and monitoring applications, including traffic signal control (such as learning what does yield mean in driving), freeway management, ramp metering, toll road monitoring, and more.

Types Of Traffic Sensors

There are different types of traffic sensors, but the most common type is the inductive loop sensor. These sensors consist of loops of wire buried in the surface of a roadway that detects changes in electrical current as a car passes over them. These sensors employ a variety of technologies.

How Much Do Traffic Lights Weigh, Sensor Types: #1. Induction Loops

Induction loops are the most common and reliable traffic light sensors. They are wire coils embedded in the road’s surface that detect changes in the inductance and transmit them to sensor circuitry to produce signals.

The loop is typically fed a fixed frequency from a generator, producing an induced magnetic field. The coils will achieve a stronger field that can last for some time even after you open the switch, as the magnetic field continues to build due to the continuous flow of current.

How Much Do Traffic Lights Weigh, Sensor Types: #2. Radar Detectors

The device emits radio waves, targets roadways, and calculates the time delay of the return signal. Based on this information, it can determine the speed of vehicles approaching an intersection and whether they will be able to stop in time.

How Much Do Traffic Lights Weigh, Sensor Types: #3. Video Detection

Video detection sensors analyze the video feed from an attached camera and then send a signal when it detects movement. This can be useful, from alerting you when someone enters your lane to controlling traffic.

However, video sensors are less popular because they are more susceptible to bad weather, produce false positives due to glare from car headlights and shadows cast by vehicles in adjacent lanes, and require more expensive tech.

How Much Do Traffic Lights Weigh, Sensor Types: #4. Geomagnetic Vehicle Detection

How Much Do Traffic Lights Weigh

Geomagnetic vehicle detection recognizes cars by catching changes in magnetic fields on traffic light systems. Radar detection detects moving vehicles (although it is frequently used for pedestrian detection because radars are rarely immobile). Laser detection measures the vehicle’s distance from the intersection (or road surface).

How Much Do Traffic Lights Weigh, Sensor Types: #5. Infrared Sensors

One of the most commonly used traffic sensors in traffic lights is the infrared sensor. On installation, you mount them above intersections so they detect incoming vehicles. The two known types of infrared traffic sensors are passive and active.

  • An active infrared sensor discharges a relatively low-level infrared energy into a specific zone to detect vehicles. When the energy is disrupted by the car, a signal is sent by the sensor to the traffic signal, and the light changes.
  • A passive infrared sensor (PIR) is a device that detects infrared radiation (heat) emitted by objects in its field of view. The device sends an alarm to a user if it detects any significant change in the amount of infrared radiation.

How Are Sensors Used At Traffic Lights

The traffic lights at your local intersection use sensors to detect vehicles approaching the intersection from each direction of travel. These sensors, usually located on top of or near the traffic light itself, are connected to an electrical circuit monitored by a computer inside the traffic light’s control box.

The computer compares the time it takes for each vehicle to reach the intersection with its pre-programmed reaction time. If it detects a car, it sends an electronic signal back to the computer that tells it to change to the next color. This process repeats until all vehicles have cleared the intersection.

Traffic cameras sometimes use signals to ensure motorists stay within the correct lane. The cameras can detect vehicles passing through red lights and help police identify offenders.

Big Traffic Light

A traffic light lens has an approximate diameter of 8 to 12 inches. A complete traffic signal with an 8-inch lens is about 30 inches tall, 9.5 inches wide, and 6 inches deep. A complete traffic signal with a 12-inch lens is 42 inches tall, 13.5 inches wide, and 8 inches deep.

Big traffic lights are used in urban and well-dense areas with a high population. Big traffic lights are necessary for these areas because of the number of cars stuck at intersections. These lights are made big to allow drivers easy recognition of the colors. Cars from afar can also see the color of the light from a far distance.

Signals For Pedestrians

Pedestrian signals alert pedestrians when it is safe to cross a street. Most pedestrian signal heads have two lights: a ‘walk’ light (typically a walking human figure in green or white) and a ‘don’t walk’ light (typically a red man figure or a hand), though other variations exist.

Crossings At Mid-Block

A signal-controlled crossing may be provided as an alternative to a zebra crossing or an uncontrolled crossing where pedestrians need to cross the road between junctions. You’ll see them at crossings with high vehicle speeds, high vehicle or pedestrian flows, or near signalized junctions.

Mini Traffic Lights VS Standard Traffic Lights

The main difference between mini traffic lights and standard traffic lights is size. Mini traffic lights are smaller, making them more portable and easier to store when not in use. They also take less energy to operate, which makes them more cost-effective than standard traffic lights. Mini traffic lights are a great alternative to standard traffic lights. They are also easier to install and maintain because they don’t require extensive cabling.

The most common place you can find mini traffic lights is at intersections where the lines are painted on the road or sidewalk. This is especially true when there is no need for a permanent stop line or stop bar at an intersection because there is no crosswalk or pedestrian crossing area nearby.

You can also use mini traffic lights for road safety at construction sites with construction workers and equipment. Another place you can set up mini traffic lights is anywhere that needs a temporary stop or slow down sign.

You may find them at event spaces as part of decorative displays or installations and can also use them at temporary road closures while an event takes place because they’re less expensive than full-size versions.

History Of Traffic Lights

On December 9, 1868, the first traffic signal system was installed to replace police officers’ control of vehicular traffic outside the Houses of Parliament in London. During the first two decades of the twentieth century, America began using semaphore traffic signals, with each state having its design.

Traffic officers controlled the traffic signal. They would blow a whistle before changing the commands on this signal to alert travelers of the change. Lester Wire, a police officer in Salt Lake City, Utah, invented the first electric traffic light in 1912.

He was concerned that police officers couldn’t change their lights at once at four different light signals. The solution was a third light in the color yellow, also used on the railroad. Automatic timers were first used to control traffic towers in 1922.

With the rise of computers in America in the 1950s, traffic light control took a significant turn. In 1952, one of the best historical examples of computerized lighting control was in Denver. Toronto was the first to use more advanced computers better at vehicle detection in 1967. The computers maintained control over 159 signals in the cities through telephone lines.

Facts about Traffic Lights:

  1. The average traffic light has a height of about 30 inches, with each lens having a width of about 9.5 inches and six inches deep.
  2. Traffic lights can weigh anywhere between 30 and 50 lbs, with aluminum traffic lights generally weighing more than plastic or polypropylene traffic lights.
  3. Most traffic lights have housings of molded polycarbonate with supporting poles of galvanized steel.
  4. Traffic lights also have an electronic controller in a weatherproof housing that’s buried in one of the corners of an intersection.
  5. Installing traffic lights involves making underground electrical conduits between each signal support location and the controller.
  6. Traffic lights are placed in areas with higher traffic rates than others, and the size of a traffic light varies depending on its intended location.
  7. Traffic light installation can cost anywhere between $200,000 and $500,000, depending on the complexity of the intersection.
  8. Some traffic lights fail to detect small vehicles like bicycles and motorcycles because the induction loop sensor is programmed to detect vehicles of a certain mass.
  9. The first traffic light was built in 1868 in London, and the first electric traffic light was installed in Cleveland, Ohio, in 1914.
  10. Developers have begun to redesign the modern traffic light by improving its capabilities and integrating artificial intelligence (AI) into its system, with some cities having traffic lights that are controlled in real-time.

FAQs On How Much Do Traffic Lights Weigh

If you’re curious to learn more about how much do traffic lights weigh, our FAQs here might help…

How Tall Is A Traffic Light

While there is no specific law governing how tall traffic lights must be, they are typically 18 feet above the ground. The traffic lights are much larger than you expect, standing about four feet tall on average.

How Big Are Traffic Lights

Every driver knows they must stop at a traffic light or risk receiving a ticket (or worse), but have you ever considered how large those lights are? Each one varies in size according to where you want to use it. Even though traffic light lenses appear small when suspended in midair, a traffic light lens is much larger than you think! The most common traffic light pattern is the standard three-light pattern with eight-inch lenses. Each lens is the size of a human head, measuring 9.5 inches wide and six inches deep. These traffic lights stand 30 inches tall when stacked on top of one another. A street light pole’s average height is between 9 and 14 feet. There are, however, smaller ones ranging from 5 to 6.5 feet. You’ll find them in pedestrian areas rather than on roads.

How Tall Is A Stop Sign

Stop signs are 4 feet 6 inches above the midpoint grade of the roadway. Where cars park or other hindrances are present, the ground level of these signs must be at least 7 feet but no more than 9 feet.

How Heavy Are Traffic Lights

A typical aluminum traffic light weighs about 37 pounds. The weight of traffic lights depends on the material of the signal’s body. The United States and Canada traffic lights are made of aluminum and plastic. Some older signals may have used cast iron, at least for a few parts. An aluminum signal weighs more than a plastic signal since the material is heavier.

How Much Does A Traffic Light Cost

Traffic lights cost $250,000 to $300,000 to install including labor cost. You can find them at intersections and also at pedestrian crossings. A computer system controls traffic lights in the UK. It detects when cars are waiting at a junction and then turns the light green when it is safe.

How Long Are Traffic Lights

The red traffic light lasts 60 to 120 seconds and takes the same time to turn green. Yellow lights have a shorter span. Traffic signals are timed to provide adequate green time for vehicles in all lanes at an intersection. The length of green time depends on the volume of traffic and the number of lanes at an intersection.

What Is A Traffic Light

Traffic lights are clusters of red, amber, and green at intersections. They direct traffic by signaling when vehicles must stop and when they can proceed. A traffic light is another name for a traffic light.

What Are The Three Traffic Signals

The three traffic signals are red, yellow, and green. The red light means stop. The green light means you can begin or continue driving. Yellow light means you should stop when it is safe because the light is about to turn red. Traffic at intersections is directed using traffic light signals. They are found in many different countries around the world.

Why Do We Need Traffic Lights

Traffic signals are used to direct traffic and control traffic flow on streets, roads, and highways. They are also used to regulate pedestrian crossing at intersections and stairways. Traffic signals use different colors and shapes to communicate what drivers should do to avoid accidents.  Traffic signals are one of the most common forms of traffic control devices. They use a combination of lights (red, yellow, and green) and arrows to control intersectional traffic.  The most common traffic light has three colors: red, green, and yellow. Red is for intersections where vehicles stop before proceeding through an intersection or crossing. A green light means go, while a flashing yellow means caution or yield. An amber or yellow light indicates that an operation phase is ending soon or has just ended, and vehicles should prepare to stop.

Conclusion On How Much Do Traffic Lights Weigh

We cannot exclude traffic lights from topics that concern transportation. This cuts across the different modes of transportation. Interestingly, their weight affects their price.  Traffic lights vary in weight because of the materials used in their construction and installation, though the most common (aluminum) weighs 37 pounds.
